The engine is an inline-4 unit, coded as 102.985, featuring a displacement of 2298 cm³ (140.2 cu-in). It operates on petrol and utilizes a Bosch CIS-E (KE-Jetronic) multi-point fuel injection (MPI) system. The engine is longitudinally aligned and is naturally aspirated with a compression ratio of 9.0:1. Its bore and stroke measure 95.5 mm x 80.2 mm (3.76 x 3.16 inches), and it incorporates 8 valves.
This engine produces a maximum power output of 132 PS (130 HP / 97 kW) at 5100 rpm and delivers a peak torque of 198 Nm (146 lb-ft) at 3500 rpm. The power is sent to the rear wheels (RWD) via a 5-speed manual transmission, providing a dynamic driving experience.
Mercedes Benz W201 190E 2.3 Engine Technical Data
| Engine type – Number of cylinders | Inline 4 |
| Engine Code | 102.985 |
| Fuel type | Petrol |
| Fuel System | MPI – Bosch CIS-E (KE-Jetronic) |
| Engine Alignment | Longitudinal |
| Engine size – Displacement – Engine capacity | 2298 cm3 / 140.2 cu-in |
| Bore x Stroke | 95.5 x 80.2 mm 3.76 x 3.16 inches |
| Number of valves | 8 Valves |
| Aspiration | N/A |
| Compression Ratio | 9.0 |
| Maximum power – Output – Horsepower | 132 PS / 130 HP / 97 kW @ 5100 rpm |
| Maximum torque | 198 Nm / 146 lb-ft @ 3500 rpm |
| Drive wheels – Traction – Drivetrain | RWD |
| Transmission Gearbox – Number of speeds | 5 speed Manual |
Mercedes Benz W201 190E 2.3 Fuel Consumption (Economy), Emissions and Range
This engine offers a combined fuel consumption rate of 9.1 L/100 km, translating to approximately 31 MPG in the UK and 26 MPG in the US. With a fuel tank capacity of 55 liters (14.5 US gallons or 12.1 UK gallons), the vehicle can cover a range of about 604 km (375 miles) on a full tank. Estimated CO2 emissions are around 217 g/km, reflecting its efficiency in both performance and environmental impact.
| Fuel Consumption – Economy – Combined | 9.1 L/100 Km 31 MPG UK 26 MPG US |
| Range | 604 Km / 375 miles |
| Fuel Tank Capacity | 55 L 14.5 US gallons 12.1 UK gallons |
| CO2 emissions | 217 g/Km (estimate) |
Mercedes Benz W201 190E 2.3 Performance
The engine allows the vehicle to reach a top speed of 197 km/h (122 mph), with an acceleration from 0 to 100 km/h (0 to 62 mph) in 10.6 seconds. This performance showcases a balanced blend of speed and responsiveness, suitable for both everyday driving and longer journeys.
| Top Speed | 197 Km/h / 122 Mph |
| Acceleration 0 to 100 km/h (0 to 62 mph) | 10.6 s |
Mercedes Benz W201 190E 2.3 Size, Dimensions, Aerodynamics and Weight
This vehicle features 4 doors and provides seating for up to 5 occupants. It has a wheelbase of 266.0 cm (104.72 inches), a length of 445.0 cm (175.2 inches), a width of 169.0 cm (66.54 inches), and a height of 138.0 cm (54.33 inches), offering a balanced and compact form. The trunk capacity stands at 410 liters (14.5 cu-ft), ensuring adequate storage space.
The front and rear braking systems utilize disc brakes, while both the front and rear tires are sized 185/65 R15. The car weighs 1220 kg (2690 lbs), resulting in a weight-to-power ratio of 9.2 kg/hp, offering an efficient balance between power and mass.
In terms of suspension, the front utilizes a McPherson setup with an anti-roll bar, while the rear features a multilink system, also equipped with an anti-roll bar. These contribute to a stable and comfortable ride quality. The aerodynamic drag coefficient (Cx) remains unspecified.
| Num. of Doors | 4 |
| Wheelbase | 266.0 cm / 104.72 in |
| Length | 445.0 cm / 175.2 in |
| Width | 169.0 cm / 66.54 in |
| Height | 138.0 cm / 54.33 in |
| Num. of Seats | 5 |
| Aerodynamic drag coefficient – Cx | – |
| Front Brakes – Disc dimensions | Discs (- mm / – in) |
| Rear Brakes – Dics dimensions | Discs (- mm / – in) |
| Front Tyres – Rims dimensions | 185/65 R15 |
| Rear Tyres – Rims dimensions | 185/65 R15 |
| Curb Weight | 1220 Kg / 2690 lbs |
| Weight-Power Output Ratio | 9.2 kg/hp |
| Trunk / Boot capacity | 410 L / 14.5 cu-ft |
| Front Suspension | McPherson with anti-roll bar |
| Rear Suspension | Multilink with anti-roll bar |
