The engine is a 2.0-liter inline 4-cylinder petrol unit, coded as 102.962. Featuring Bosch KE-Jetronic fuel injection, this engine is designed with a longitudinal alignment, offering a displacement of 1997 cm³ (121.9 cu-in). With a bore and stroke of 89.0 mm by 80.2 mm (3.5 x 3.16 inches), it operates with 8 valves and no forced induction, delivering a naturally aspirated setup. The compression ratio stands at 9.1, allowing the engine to produce a maximum output of 122 PS (120 HP or 90 kW) at 5100 rpm and a peak torque of 172 Nm (126 lb-ft) at 3500 rpm. Power is sent to the rear wheels (RWD) through a 5-speed manual transmission, providing a dynamic driving experience.
Mercedes Benz W201 190E 5sp Engine Technical Data
| Engine type – Number of cylinders | Inline 4 |
| Engine Code | 102.962 |
| Fuel type | Petrol |
| Fuel System | Bosch KE-Jetronic 3.5 |
| Engine Alignment | lLongitudina |
| Engine size – Displacement – Engine capacity | 1997 cm3 / 121.9 cu-in |
| Bore x Stroke | 89.0 x 80.2 mm 3.5 x 3.16 inches |
| Number of valves | 8 Valves |
| Aspiration | N/A |
| Compression Ratio | 9.1 |
| Maximum power – Output – Horsepower | 122 PS / 120 HP / 90 kW @ 5100 rpm |
| Maximum torque | 172 Nm / 126 lb-ft @ 3500 rpm |
| Drive wheels – Traction – Drivetrain | RWD |
| Transmission Gearbox – Number of speeds | 5 speed Manual |
Mercedes Benz W201 190E 5sp Fuel Consumption (Economy), Emissions and Range
This engine offers a combined fuel consumption of 8.9 L/100 km, which translates to 32 MPG in the UK and 26 MPG in the US. With a fuel tank capacity of 55 liters (14.5 US gallons or 12.1 UK gallons), the vehicle has an estimated driving range of 617 km (383 miles) on a full tank. CO2 emissions are approximately 212 g/km, making it a relatively efficient option for its time.
| Fuel Consumption – Economy – Combined | 8.9 L/100 Km 32 MPG UK 26 MPG US |
| Range | 617 Km / 383 miles |
| Fuel Tank Capacity | 55 L 14.5 US gallons 12.1 UK gallons |
| CO2 emissions | 212 g/Km (estimate) |
Mercedes Benz W201 190E 5sp Performance
This engine delivers a top speed of 190 km/h (118 mph) and accelerates from 0 to 100 km/h (0 to 62 mph) in 10.9 seconds. These performance figures highlight a balanced mix of efficiency and power, making it suitable for both city driving and longer journeys.
| Top Speed | 190 Km/h / 118 Mph |
| Acceleration 0 to 100 km/h (0 to 62 mph) | 10.9 s |
Mercedes Benz W201 190E 5sp Size, Dimensions, Aerodynamics and Weight
This 4-door vehicle offers a spacious interior with seating for 5 passengers. It has a wheelbase of 266.0 cm (104.72 in), a length of 445.0 cm (175.2 in), a width of 169.0 cm (66.54 in), and a height of 138.0 cm (54.33 in). The aerodynamic drag coefficient (Cx) is not specified, but it ensures stability at higher speeds.
Braking is managed by disc brakes on both the front and rear, while the exact dimensions of the discs are unspecified. The car rides on 185/65 R15 tires both at the front and rear, providing a balanced grip.
Weighing in at 1170 kg (2579 lbs), the car achieves a weight-to-power ratio of 9.6 kg/hp. Its trunk/boot offers a generous 410 liters (14.5 cu-ft) of cargo space. The front suspension is a McPherson setup with an anti-roll bar, while the rear features a multilink suspension with an anti-roll bar, ensuring a comfortable and controlled ride.
| Num. of Doors | 4 |
| Wheelbase | 266.0 cm / 104.72 in |
| Length | 445.0 cm / 175.2 in |
| Width | 169.0 cm / 66.54 in |
| Height | 138.0 cm / 54.33 in |
| Num. of Seats | 5 |
| Aerodynamic drag coefficient – Cx | – |
| Front Brakes – Disc dimensions | Discs (- mm / – in) |
| Rear Brakes – Dics dimensions | Discs (- mm / – in) |
| Front Tyres – Rims dimensions | 185/65 R15 |
| Rear Tyres – Rims dimensions | 185/65 R15 |
| Curb Weight | 1170 Kg / 2579 lbs |
| Weight-Power Output Ratio | 9.6 kg/hp |
| Trunk / Boot capacity | 410 L / 14.5 cu-ft |
| Front Suspension | McPherson with anti-roll bar |
| Rear Suspension | Multilink with anti-roll bar |
