Mercedes Benz W201 190D 2.5 Turbo Engine Technical Data
Engine type – Number of cylinders | Inline 5 |
Engine Code | 602.961 |
Fuel type | Diesel |
Fuel System | Bosch |
Engine Alignment | Longitudinal |
Engine size – Displacement – Engine capacity | 2497 cm3 / 152.4 cu-in |
Bore x Stroke | 87.0 x 84.0 mm 3.43 x 3.31 inches |
Number of valves | 10 Valves |
Aspiration | Turbo |
Compression Ratio | 22.0 |
Maximum power – Output – Horsepower | 122 PS / 120 HP / 90 kW @ 4600 rpm |
Maximum torque | 225 Nm / 165 lb-ft @ 2400 rpm |
Drive wheels – Traction – Drivetrain | RWD |
Transmission Gearbox – Number of speeds | 4 speed Automatic |
Mercedes Benz W201 190D 2.5 Turbo Fuel Consumption (Economy), Emissions and Range
Fuel Tank Capacity | 55 L 14.5 US gallons 12.1 UK gallons |
CO2 emissions | – g/Km (Mercedes Benz) |
Mercedes Benz W201 190D 2.5 Turbo Performance
Top Speed | 195 Km/h / 121 Mph |
Acceleration 0 to 100 km/h (0 to 62 mph) | – s |
Mercedes Benz W201 190D 2.5 Turbo Size, Dimensions, Aerodynamics and Weight
This 4-door vehicle offers a spacious interior with seating for 5 passengers. It has a wheelbase of 266.0 cm (104.72 in), a length of 442.0 cm (174.02 in), a width of 168.0 cm (66.14 in), and a height of 139.0 cm (54.72 in). Although the aerodynamic drag coefficient (Cx) is unspecified, the car is designed for stability and efficiency at higher speeds.
The vehicle is equipped with disc brakes at both the front and rear, although the exact dimensions of the discs are not specified. It rides on 185/65 R15 tires at the front and rear, providing good road grip and comfort.
With a curb weight of 1270 kg (2800 lbs), the car has a weight-to-power ratio of 10.4 kg/hp. It also offers a trunk/boot capacity of 410 liters (14.5 cu-ft), making it practical for daily use and long trips
Num. of Doors | 4 |
Wheelbase | 266.0 cm / 104.72 in |
Length | 442.0 cm / 174.02 in |
Width | 168.0 cm / 66.14 in |
Height | 139.0 cm / 54.72 in |
Num. of Seats | 5 |
Aerodynamic drag coefficient – Cx | – |
Front Brakes – Disc dimensions | Discs (- mm / – in) |
Rear Brakes – Dics dimensions | Discs (- mm / – in) |
Front Tyres – Rims dimensions | 185/65 R15 |
Rear Tyres – Rims dimensions | 185/65 R15 |
Curb Weight | 1270 Kg / 2800 lbs |
Weight-Power Output Ratio | 10.4 kg/hp |
Trunk / Boot capacity | 410 L / 14.5 cu-ft |
