This Honda C32A1 engine is a transverse, front-mounted V6 petrol engine with a displacement of 3206 cm³ (195.6 cu-in). It features Honda’s PGM-Fi fuel injection system and water cooling, with an 8.7 L (9.19 quarts) coolant capacity. The bore and stroke are 90.0 mm x 84.0 mm (3.54 x 3.31 inches), and the engine has 24 valves with a compression ratio of 9.6. This naturally aspirated engine delivers a maximum output of 230 PS (227 HP / 169 kW) at 6200 rpm and a peak torque of 279 Nm (205 lb-ft) at 5000 rpm. The car is front-wheel drive (FWD) and equipped with a 6-speed manual transmission, providing a dynamic driving experience.
Acura Legend 2 Coupe 3.2 V6 Engine Technical Data
| Engine type – Number of cylinders | V 6 |
| Engine Code | Honda C32A1 |
| Fuel type | Petrol |
| Fuel System | Honda PGM-Fi fuel injection |
| Lubrication | Wet sump Lubrication |
| Engine Cooling | Water |
| Engine Cooling – Capacity | 8.7 L / 9.19 quarts |
| Engine Alignment | Transverse |
| Engine Position | Front |
| Engine size – Displacement – Engine capacity | 3206 cm3 / 195.6 cu-in |
| Bore x Stroke | 90.0 x 84.0 mm 3.54 x 3.31 inches |
| Number of valves | 24 Valves |
| Aspiration | N/A |
| Compression Ratio | 9.6 |
| Maximum power – Output – Horsepower | 230 PS / 227 HP / 169 kW @ 6200 rpm |
| Maximum torque | 279.0 Nm / 205 lb-ft @ 5000 rpm |
| Drive wheels – Traction – Drivetrain | FWD |
| Transmission Gearbox – Number of speeds | 6 speed Manual |
Acura Legend 2 Coupe 3.2 V6 Fuel Consumption (Economy), Emissions and Range
This vehicle, with its V6 engine, has an EPA-estimated fuel consumption of 25 L/100 km (11 MPG UK / 9 MPG US) on the highway, 17 L/100 km (17 MPG UK / 14 MPG US) in the city, and a combined rating of 20 L/100 km (14 MPG UK / 12 MPG US). With a fuel tank capacity of 68 liters (18 US gallons / 15 UK gallons), it offers a range of approximately 576 km (358 miles) under EPA standards, balancing performance with adequate range for extended journeys.
| Fuel Consumption – Economy – EPA Highway ( – 2008) | 25 L/100 Km 11 MPG UK 9 MPG US |
| Fuel Consumption – Economy – EPA City ( – 2008) | 17 L/100 Km 17 MPG UK 14 MPG US |
| Fuel Consumption – Economy – EPA Combined ( – 2008) | 20 L/100 Km 14 MPG UK 12 MPG US |
| Range (EPA) | 576 Km / 358 miles |
| Fuel Tank Capacity | 68 L 18 US gallons 15 UK gallons |
Acura Legend 2 Coupe 3.2 V6 Performance
The top speed and acceleration for this vehicle are unspecified in the provided details. However, with a 230 PS (227 HP) V6 engine and a 6-speed manual transmission, this model is likely designed for strong mid-range power and smooth acceleration, ideally suited for both urban and highway driving. The combination of power and front-wheel drive should offer a responsive performance profile even without exact speed figures.
| Top Speed | – Km/h / – Mph |
| Acceleration 0 to 100 km/h (0 to 62 mph) | – s |
Acura Legend 2 Coupe 3.2 V6 Size, Dimensions, Aerodynamics and Weight
This coupé features a sleek 2-door body with a substantial wheelbase of 283 cm (111.42 in) and an overall length of 489 cm (192.52 in). It measures 181 cm (71.26 in) in width and 136 cm (53.54 in) in height, with a ground clearance of 15.3 cm (6.02 in). The aerodynamic drag coefficient (Cx) is an efficient 0.32, supporting its performance.
The braking system includes 280 mm (11.02 in) vented disc brakes at both the front and rear, complemented by 205/60 R15 tires on 6.5-inch rims for both axles. The car has a turning radius of 10.4 meters (34.1 feet), making it manageable in tight spaces. Weighing in at 1580 kg (3483 lbs), the vehicle has a weight-to-power ratio of 6.9 kg/hp, balancing power and stability.
Cargo space is a generous 399 liters (14.1 cu-ft). Steering is rack and pinion with speed-sensitive, variable power assistance, providing precision and ease of handling. The suspension setup includes an independent double-wishbone design with coil springs and stabilizer bars (28.6 mm front and 19.1 mm rear), ensuring both comfort and stability on the road.
| Body | Coupé |
| Num. of Doors | 2 |
| Wheelbase | 283 cm / 111.42 in |
| Length | 489 cm / 192.52 in |
| Width | 181 cm / 71.26 in |
| Height | 136.0 cm / 53.54 in |
| Front Axle | 155.0 cm / 61.02 in |
| Rear Axle | 154.0 cm / 60.63 in |
| Ground clearance | 15.3 cm / 6.02 in |
| Aerodynamic drag coefficient – Cx | 0.32 |
| Front Brakes – Disc dimensions | Vented Discs (280 mm / 11.02 in) |
| Rear Brakes – Dics dimensions | Discs (280 mm / 11.02 in) |
| Front Tyres – Rims dimensions | 205/60 R15 |
| Rear Tyres – Rims dimensions | 205/60 R15 |
| Front Wheels Width | 6.5″ |
| Rear Wheels Width | 6.5″ |
| Turning radius | 10.4 m / 34.1 feet |
| Curb Weight | 1580 Kg / 3483 lbs |
| Weight-Power Output Ratio | 6.9 kg/hp |
| Trunk / Boot capacity | 399 L / 14.1 cu-ft |
| Steering | Rack and pinion Speed-sensitive, variable power assisted |
| Front Suspension | Independent double wishbone with coil springs and stabilizer bar (28.6 mm) |
| Rear Suspension | Independent double-wishbone with dual trailing arms, roil springs and stabilizer bar (19.1 mm) |
